VM1R series Two-Way Radio Communication Headsets


Sensear provides industry-leading two-way radio headsets to the world’s top industrial companies. Users can have clear two-way radio communication in high noise environments with hearing protection up to 25dB. A noise cancelling boom microphone enables clear radio transmissions.

The VM1R Series is built specifically to enhance two-way radio communication in high-noise environments. The headset is powered by the radio making it a lightweight heavy-duty solution to your two-way radio communication needs.

Here are just some of the many features and benefits that these Sensear’s two-way radio headset products have to offer.



BUY NOW
REQUEST A QUOTE

Why Sensear's VM1R Series is a good addition to your communication system

Below features make VM1R Series: Sensear's Two-way Radio Communication Headsets the right solution for you.

Clear two-way radio communication
Hearing protection for high-noise work environments
Connects to industry leading two-way radios
Noise Reduction range of 21-25 dB
Noise-cancelling boom mic.
Highly durable and lightweight

Headband, Behind-the-Head or Helmet Mount style
VOX capable
No battery, powered by the radio
  • Clear two-way radio communication in high noise environments
  • Connects industry leading two way radios
  • Available in Headband, Behind-the-Head and Helmet Mounted styles
  • Durable and lightweight design
  • VOX capable when used with a VOX activated two-way radio
  • Noise Reduction range of 21-25 dB.
  • Noise-canceling boom mic

DOWNLOAD THE FULL DATASHEET

Specification



VM1RB001 / VM1RH001
VM1RE001

Speaker

Impedance

32Ω
32Ω

Frequency Range

100Hz ~ 3KHz
100Hz ~ 20KHz

Power Rating

Normal 30mW RMS
Maximum 100mW
Normal 50mW RMS
Maximum 100mW

Output SPL

95±3dB /1mW /1cm
95±3dB /1mW /1cm

Microphone

Type

Noise Cancelling Dynamic Mic
Noise Cancelling Dynamic Mic

Sensitivity

-71dB ±3dB
-47dB ±3dB

Impedance

150 Ω
2.2 KΩ

Frequency Range

150Hz ~ 7000Hz
100Hz10KHz

Boom Type

Flexible
Heavy duty flexible

Headband /
BTN Overhead strap

Padded headband for increased comfort,
Adjustable headband
Behind the head metal band with overhead strap

Ear pad cushion

Gel
Gel

Plug

Microphone & Earphone 5P Mini Chassis XLR Connector, Male
Microphone & Earphone 5P Mini Chassis XLR Connector, Male

Color

Black
Black

Switch

Push To Talk Button (PTT)
Push To Talk Button (PTT)

Operating Range

-20 ~ 90°C
-20 ~ 90°C

Weight

VM1RB001 = 385gms, VM1RH001 = 420gms
VM1RE001 = 445gms



Information


VM1R Datasheet



These products are sold separately BUY NOW - Accessories & Parts (VM1R)

VMS00001

Earmuff hygiene kit gel ear seals

Earmuff hygiene kit gel ear seals

VMS00002

Replacement dynamic microphone

Replacement dynamic microphone

VMS00003

VMS00003 (Boom_Mic_Assembly_BTH)

Replacement Electret microphone and boom assembly

VMS00004

VMS00004

Foam Boom Mic Cover

VMS00007

VMS00004

Foam Boom Mic Cover

VMS00005

VMS00005

Behind Headset Velcro Strap

VMS00006

VMS00006 (Replacement HeadBand)

Foam Head Pads with Metal

Need a Radio Cable for VM1R BUY NOW - Cables (VM1R)

Part Number

Product Description

VRCK1014 VM1R series Two-Way Radio Cable for Motorola GCAI (Mototrbo, APX)
VRCK1066 VM1R series Two-Way Radio for Motorola Slim (Mototrbo)
VRCK1009 VM1R series Two-Way Radio for Motorola 2-pin
VRCK1013 VM1R series Two-Way Radio for Kenwood 2-pin
VRCK1299 VM1R series Two-Way Radio for HYT 2-pin

 OR

Please submit the completed form below, so we can get back to you with information and available radio cables.
